VFD Cable Manufacturer in India
Elegar Kerpen manufactures VFD cables that meet the demands of modern drive systems. With voltage grades up to 1800/3300V AC, flexible copper conductors, and insulation options including XLPE, EPR, and HEPR, every cable is built to protect your motors and reduce downtime, making it a reliable choice for engineers across industries.
Why Choose US
ISO-Certified Manufacturing Excellence
Applications of VFD Cable
- Industrial Automation: VFD cables connect motor drives to automated machinery where accurate speed control is critical. They suppress noise that would otherwise disturb control signals and nearby low-voltage wiring, keeping operations stable.
- Oil and Gas: In offshore and hazardous locations, a VFD motor cable must handle mechanical stress, chemical exposure, and high voltage transients at the same time. Elegar Kerpen offers sheathing options such as ZHFR and SHF1/SHF2 that are built for these demanding conditions.
- Mining: Mining sites need cables that can take abrasion, moisture, and constant movement. VFD cables used in mining must consistently handle the high-frequency switching of heavy machinery without any loss in signal quality.
- Chemical and Process Plants: These facilities use variable frequency drive systems to control pump and fan speeds. VFD cables with proper shielding prevent interference with sensitive instruments running nearby on the same installation.
- Marine and Offshore: Medium voltage VFD cable used on vessels and offshore platforms faces vibration, saltwater exposure, and strict electrical compatibility requirements. Elegar Kerpen cables are constructed to perform reliably in all these conditions.
- HVAC and Building Services: Large HVAC systems use VFD-controlled motors for energy-efficient operation. Correctly rated VFD cables stop noise from affecting building control systems and communication networks running in the same area.
VFD Cable Specifications
| Construction | Metallic layer over the core / cable will reduce the noise / strong electric field around the core / earthing of all spikes generated during the operation. |
| Voltage Grade | Up to 1800 / 3300 V AC |
| Conductor | Circular electrolytic bare copper / tinned copper (stranded / flexible) |
| Insulation | XLPE or EPR or HEPR |
| Screening | Combination of copper tape and copper wire braid or double layer of copper tape and concentric braiding |
| Outer Sheath | PVC / ZHFR / SHF1 / SHF2 |
VFD Cable Standards
As a dependable wires and cables manufacturer, Elegar Kerpen designs and produces VFD cable solutions in accordance with widely accepted industry standards. Our VFD cables are developed to meet strict electrical and mechanical specifications, ensuring reliable performance, safety, and long service life in demanding variable frequency drive applications.
- IS: 7098 (Pt-1)
- IEC: 60502-1
- BS: 5467
- BS: 6346
- AS/NZS 5000.1
These standards help ensure consistent quality, resistance to electrical stress, and suitability for VFD motor cable installations across industrial, commercial, and process environments. Elegar Kerpen focuses on delivering cables that meet global expectations for reliability in variable frequency drive systems.
Why Choose Elegar Kerpen's VFD Cable?
As a trusted wires and cables manufacturer, Elegar Kerpen brings solid engineering and hands-on application knowledge to its VFD cable range. Here is what makes their cables stand out:
- Strong Conductor Design: Circular electrolytic bare copper or tinned copper conductors, available in stranded or flexible form, make installation easy and ensure long service life even in high-movement environments. Tinned copper also resists oxidation over time.
- Multiple Insulation Options: XLPE, EPR, and HEPR insulation choices cover a wide range of temperature and chemical resistance needs, making it straightforward to pick the right cable for your drive application.
- Reliable EMC Shielding: A combination of copper tape and copper wire braid, or a double layer of copper tape with concentric braiding, creates a low-resistance ground return path. This controls the high-frequency noise common in variable frequency drive systems and supports electrical compatibility requirements.
- Sheath Options for Every Environment: PVC, ZHFR, SHF1, and SHF2 sheath choices cover different site conditions, from standard industrial setups to low smoke, halogen-free installations where safety in enclosed spaces is a priority.
- High Voltage Rating: Rated up to 1800/3300V AC, Elegar Kerpen's VFD cables are built to handle voltage spikes that go beyond the normal operating level, which is a regular occurrence in high-frequency switching systems.
As a dependable wire cable company, Elegar Kerpen combines proven cable construction with application-focused design to deliver cables that protect your motors, limit downtime, and extend the life of your system.
Frequently Asked Questions
Find answers to frequently asked questions related to VFD Cables.
A VFD cable is built to handle high-frequency voltage spikes, electrical noise, and stress produced by variable frequency drive systems. Regular power cables are not rated for these conditions and can fail or degrade much faster in such environments.
Cable length affects how voltage behaves in VFD systems. Longer runs increase voltage reflection, which can harm motors and drives. It is always best to follow the drive manufacturer's guidelines and plan cable runs carefully, especially for distances beyond recommended limits.
Medium voltage VFD cable is commonly used in oil and gas, mining, marine, and large industrial processing plants where high-power motors need to be controlled by variable frequency drives and standard low-voltage cables are not suitable.
Elegar Kerpen provides XLPE, EPR, and HEPR insulation options. Each type suits different temperature ratings, flexibility needs, and levels of chemical resistance based on where the cable will be used.
Yes. A well-shielded VFD cable provides a proper path for high-frequency ground currents, which lowers shaft voltages that can slowly damage motor bearings. This is a known issue in systems running on variable frequency drives.
Yes. Elegar Kerpen offers ZHFR, SHF1, and SHF2 outer sheath options that are halogen-free and produce low smoke. These meet safety standards for enclosed spaces, marine vessels, and public infrastructure projects.
The right choice depends on voltage rating, conductor size, insulation type, shielding, and the environment where the cable will be installed. As one of the established wires and cables manufacturers in India, Elegar Kerpen's technical team can help you find the right specification for your drive system.
